PVC Foam Board Crust Production Line
.PVC foam board has the properties of sound insulation, sound absorption, heat insulation, heat preservation, etc.
Specifications
|
Product Name |
Semi-skinned foam board |
Semi-skinned foam board |
Semi-skinned foam board |
|
Extruder |
SJZ80/156 |
SJZ92/188 |
SJZ80/156+SJZ65/132 |
|
Main Motor Power |
55KW/75KW |
110KW |
75KW+37KW |
|
Width |
1200MM |
1560MM |
1220MM |
|
Thickness |
5-20MM |
8-18MM |
8-20MM |
|
Auxiliary |
YF1200 |
YF1560 |
YF1220 |
|
Auxiliary |
|||
|
Styling table |
Cooling rack |
Haul off/Cutter |
Turnover rack |
|
Length 2.5m |
Length 3.5m |
Tractor: pressure roller type, power 7.5kw |
Length 2m |
Features
Advantages and Features
1.PVC foam board has the properties of sound insulation, sound absorption, heat insulation, heat preservation, etc.
2.The board is flame-retardant, can prevent fire by itself, and has high safety.
3.The production line has high output and stable operation.
4.The mold adopts a special foaming plate runner structure, so that the material can be extruded and foamed evenly.
5.Traction measurement is easy to adjust and the sheet is cut straight.
